TP-Link MC210CS Gigabit Single-Mode Media Converter
Gigabit Multi-Mode Media Converter
- 1 10/100/1000Mbps Auto-Negotiation RJ45 port supporting Auto-MDI/MDIX
- Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
- Extends fiber distance up to 0.55km
Part# / SKU :
MC210CSProduct Warranty :
Three Year Limited WarrantyMEDIA CONVERTER & MODULE | |
---|---|
Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z |
Basic Function | Auto-negotiation of Half-Duplex / Full-Duplex transfer mode Extends fiber distance up to 0.55km using 50/125um fiber Extends fiber distance up to 0.22km using 62.5/125um fiber |
Ports | 1 1000M SC/UPC port 1 10/100/1000M RJ45 port (Auto MDI/MDIX) |
Wave Length | 850nm |
Network Media 1000BASE-SX | Multi-mode Fiber |
Network Media 1000BASE-T | UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
LED Indicators | PWR, Link/Act |
Dimensions (W*D*H) | 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm) |
Power Supply | External Power Adapter |
Max Power Consumption | 1.66W |
Safety & Emission | FCC, CE, RoHS |
Package Contents | • Media Converter MC200CM • Power Adapter • Installation Guide |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Brand | TP-Link |
